Int J Performability Eng ›› 2019, Vol. 15 ›› Issue (1): 317325.doi: 10.23940/ijpe.19.01.p32.317325
Previous Articles Next Articles
Yu Li^{a}^{b}, Qian Guo^{b}, and Jingsen Liu^{c}*()
Revised on
;
Accepted on
Contact:
Liu Jingsen
Email:ljs@henu.edu.cn
About author:
Yu Li received her PhD from University of Shanghai for Science and Technology. She is a professor of Institute of Management Science and Engineering, and Business School, Henan University. Her research interests include intelligence algorithms, electronic commerce, etc.Qian Guo is a master degree candidate of Business School, Henan University. Her research interest is intelligence algorithm.Jingsen Liu received his PhD from Northwestern Polytechnical University. He is a professor of Institute of Intelligent Network system, and College of Software, Henan University. His research interests include intelligence algorithm and network information security, etc.
Yu Li, Qian Guo, and Jingsen Liu. Improved Bat Algorithm for Vehicle Routing Problem [J]. Int J Performability Eng, 2019, 15(1): 317325.
Add to citation manager EndNoteReference ManagerProCiteBibTeXRefWorks
Bat algorithm
pseudo code"
Input: Initialize the bat population ${{x}_{i}}$, ${{f}_{i}}$, and ${{v}_{i}}$,$(i=1,2,\cdots ,n)$

1. While$(t<{{T}_{\max }})$;
2. Update velocities and locations;
3. If$(rand>{{r}_{i}})$;
Select a current best solution randomly among the best solutions and generate a local solution around the selected best solution;
5. End if;
6. Generate a new solution randomly;
7. If ($rand<{{A}_{i}}$and $f({{x}_{i}})<f({{x}_{*}})$);
8. $f({{x}_{*}})=f({{x}_{i}})$;
9. Increase ${{r}_{i}}$and reduce ${{A}_{i}}$;
10. End if;
11. Rank the bats and find the current best ${{x}_{*}}$;
12. End while.
Table 1
Distance and demand"
0  1  2  3  4  5  6  7  8

0  0  4  6  7.5  9  20  10  16  8
1  4  0  6.5  4  10  5  7.5  11  10
2  6  6.5  0  7.5  10  10  7.5  7.5  7.5
3  7.5  4  7.5  0  10  5  9  9  15
4  9  10  10  10  0  10  7.5  7.5  10
5  20  5  10  5  10  0  7  9  7.5
6  10  7.5  7.5  9  7.5  7  0  7  10
7  16  11  7.5  9  7.5  9  7  0  10
8  8  10  7.5  15  10  7.5  10  10  0
d  1  2  1  2  1  4  2  2
Table 3
Solution by standard GA and doublepopulation GA for 10 times"
Algorithm  Times

1  2  3  4  5  6  7  8  9  10
standard GA  74.00  75.00  71.50  72.00  73.50  75.00  73.00  72.50  75.50  73.50
doublepopulation GA  70.00  69.50  67.50  71.00  69.00  70.50  72.00  67.50  71.50  69.00
11  12  13  14  15  16  17  18  19  20
standard GA  72.00  69.00  73.00  75.50  72.00  73.00  75.00  73.50  71.50  75.00
doublepopulation GA  67.50  69.00  71.00  70.00  67.50  70.50  69.00  69.50  71.00  69.00
Table 4
Pn19k2 coordinate and demand"
Coordinate  Demand  Coordinate  Demand

0  (30,40)  0  10  (42,57)  8
1  (37,52)  19  11  (27,68)  7
2  (49,43)  30  12  (43,67)  14
3  (52,64)  16  13  (58,27)  19
4  (31,62)  23  14  (37,69)  11
5  (52,33)  11  15  (61,33)  26
6  (42,41)  31  16  (62,63)  17
7  (52,41)  15  17  (63,69)  6
8  (57,58)  28  18  (45,35)  15
9  (62,42)  14
[1]  G.B. Dantzig and J. H. Ramser , “The Truck Dispatching Problem,” Management Science,Vol. 6, No. 1, pp. 8091, 1959
[2]  N. Christofides, A. Mingozzi, P. Toth , “Exact Algorithms for the Vehicle Routing Problem based on Spanning Tree and Shortest Path Relaxations,” Mathematical Programming, Vol. 20, No. 1, pp. 255282, 1981
[3]  F. Glover and M. Laguna , “Tabu Search,” General Information, Vol. 106, No. 2, pp. 22125, 2006
[4]  D. E. Goldberg , “Genetic Algorithm in Search Optimization and Machine Learning,” Addison Wesley xiii, Vol. 7, pp. 21042116, 1989
[5]  L. M. Gambardella, E. D. Taillard, G. Agazzi , “A Multiple Ant Colony System for Vehicle Routing Problems with Time Windows, ” 1999
[6]  J. Brandão , “A Tabu Search Algorithm for the Open Vehicle Routing Problem,” European Journal of Operational Research, Vol. 157, No. 3, pp. 552564, 2004
[7]  E. Choi and D. W. Tcha , “A Column Generation Approach to the Heterogeneous Fleet Vehicle Routing Problem,” Computers & Operations Research, Vol. 34, No. 7, pp. 20802095, 2007
[8]  G. Nagy and S. Salhi , “Heuristic Algorithms for Single and Multiple Depot Vehicle Routing Problems with Pickups and Deliveries,” European Journal of Operational Research, Vol. 162, No. 1, pp. 126141, 2005
[9]  X. S. Yang , “A New Metaheuristic BatInspired Algorithm,”Computer Knowledge & Technology, Vol. 284, pp. 6574, 2010
[10]  X. S. Yang , “Bat Algorithm for MultiObjective Optimization,” International Journal of BioInspired Computation, Vol. 3, No. 5, pp. 267274, 2012
[11]  C. Karri and U. Jena , “Fast Vector Quantization using a Bat algorithm for Image Compression,” Engineering Science & Technology an International Journal, Vol. 19, No. 2, pp. 769781, 2016
[12]  A. Chakri, R. Khelif, M. Benouaret, X. S. Yang , “New Directional Bat Algorithm for Continuous Optimization Problems,”Expert Systems with Applications, Vol. 69, pp. 159175, 2017
[13]  P. Musikapun and P. Pongcharoen , “Solving MultiStage MultiMachine MultiProduct Scheduling Problem using Bat Algorithm,”International Proceedings of Economics Development & Research, Vol. 35, 2012
[14]  G. G. Wang, H. C. E. Chu, and S. Mirjalili , “ThreeDimensional Path Planning for UCAV using an Improved Bat Algorithm,” Aerospace Science & Technology, Vol. 49, pp. 231238, 2016
[15]  P. Augerat, J. M. Belenguer, E. Benaventb, A. Corberan, D. Naddef , “Separating Capacity Constraints in the CVRP using Tabu Search,”European Journal of Operational Research,Vol. 106, No.23, pp. 546557, 1998
[16]
R. C. Eberhart, Y. Shi , “Tracking and Optimizing Dynamic Systems with Particle Swarms, ” Evolutionary Computation,in Proceedings of the 2001 Congress on IEEE, Vol. 1, pp. 94100, 2001
doi: 10.1109/CEC.2001.934376
[17]  Y. Shi and R. Eberhart , “A Modified Particle Swarm Optimizer,” Advances in Natural Computation, pp. 439439, Springer Berlin Heidelberg, 1998
[18]  J. Li , “Genetic Algorithm for Vehicle Scheduling Problem with NonFull Load,” SYSTEMS ENGINETHEORY METHODOLOGY APPLICATION, 2000
