Real Time Optimization of Linux System in Aerospace

doi:10.23940/ijpe.18.12.p35.32573264

Abstract

Abstract:

The problem of poor real-time performance of standard Linux greatly limits its application in the aerospace field. Dealing with the characteristics of multi-tasks and high concurrency of the payload during the space station mission of our country, this paper analyzes Linux optimization solution based on three patches: RT patch, Xenomai, and RTAI. This paper tests the switching between tasks and preemption time to ensure the effectiveness of switching between tasks and preemption time and to avoid the problem of priority inversion. The test results show that RT-patch is suitable for units that emphasize data processing which rely heavily on IPC; Xenomai or RTAI is suitable for units that emphasize controlling processing which require better stability of real-time performance.

Key words: real-time, Linux, patch, optimization, RTOS

Yushuai Liu, Yu Su, Yunyun Ma, and Jinbo Wang. Real Time Optimization of Linux System in Aerospace [J]. Int J Performability Eng, 2018, 14(12): 3257-3264.

Add to citation manager EndNote|Reference Manager|ProCite|BibTeX|RefWorks

Figures/Tables 9

Figure 1

Figure 2

Figure 3

Table 1

Table 2

Figure 4

Table 3

Table 4

Figure 5

References 13

[1]	J. He, Y. Li, W. Zhang, F. Fang, H. Xu , “Real-Time Optimization and Application of the Embedded ARM-Linux Scheduling Policy,” in Proceedings of IEEE International Conference on Information Technology, Computer Engineering and Management Sciences, pp. 134-138, September 2011
[2]	L. Deng, X. Zhao, C. Qi, F. Gao , “A Real-Time Walking Robot Control System based on Linux RTAI,” in Proceedings of the 2013 International Conference on Advanced Mechatronic Systems, pp. 530-534, Luoyang, China, December 2013
[3]	Y. Dong and W. Han , “Real-time Research of Linux System based on the Multi-Core ARM Platform,” Journal of Chinese Computer Systems, Vol. 38, No. 6, pp. 1262-1266, June 2017
[4]	Y. Zhou and Q. Zhou , “The Embeded Real-Time Linux Operation System based on the Xenomai,” in Proceedings of International Conference on Electrical & Controling Engneering, pp. 224-226, Yichang, China, June 2011
[5]	Y. Su, T. Zhang, L. Sun , “Research on Real-Time Linux System based on Xenomai,” Computer Technology and Development, Vol. 23, No. 10, pp. 1-5, July 2013
[6]	H. Fayyad-Kazan, L. Perneel, M. Timmerman , “Linux PREEMPT-RT v2.6.33 Versus v3.6.6: Better or Worse for Real-Time Applications?” Acm Sigbed Review, Vol. 11, No. 1, pp. 26-31, February 2014
[7]	N. Saranya and R. C. Hansdah , “An Implementation of Partitioned Scheduling Scheme for Hard Real-Time Tasks in Multicore Linux with Fair Share for Linux Tasks,” in Proceedings of 2014 IEEE 20th International Conference on Embedded and Real-Time Computing Systems and Applications, pp. 1-9, Chongqing, China, September 2014
[8]	J. Yoo, Y. Jeon, J. Hong, D. Kim, S. Lee , “Design and Implementation of Real-Time Kernel Patch System for Embedded Linux,” International Journal of Applied Engineering Research, Vol. 11, No. 2, pp. 1485-1487, 2016
[9]	Z. Wang, S. Li, Y. Wang , “Researching of Real-Time Version and Testing Its Performance of CNC System based on RT-Linux,” in Proceedings of 2009 International Conference on Networking and Digital Society, pp. 174-177, Guiyang, China, February 2009
[10]	F. Gosewehr, M. Wermann, A. W. Colombo , “From RTAI to RT-Preempt a Quantative Approach in Replacing Linux based Dual Kernel Real-Time Operating Systems with Linux RT-Preempt in Distributed Real-Time Networks for Educational ICT Systems,” in Proceedings of IECON 2016-42nd Annual Conference of the IEEE on Industrial Electronics Society, pp. 6596-6601, Florence, Italy, December 2016
[11]	D.B. Oliveira and R. S. Oliveira , “Timing Analysis of the PREEMPT RT Linux Kernel,” Software Practice and Experience, Vol. 46, No. 6, pp. 789-819, May 2015
[12]	J. Bai, M. Y. Gao, K. G. Zhang, X. H. Yu, X. S. Qin , “Research on the Real-Time Module of the Industrial Robot Control System based on the RTAI,” in Proceedings of 2015 IEEE International Conference on Control System, Computing and Engineering (ICCSCE), pp. 293-297, George Town, Malaysia, November 2015
[13]	Y. Ma, Y. Q. Zhao, Z. Y. Yin , “Research on Real-Time Scheduling Method of RTAI-Linux based on EDF Algorithm,” in Proceedings of 2017 10th International Conference on Intelligent Computation Technology and Automation, pp. 58-61, Changsha, Hunan, China, October 2017

Time Patch	Context switching (us)
Time Patch	Min	Avg.	Max	STDEV
RTAI	2.03	2.53	6.69	0.67
Xenomai	3.40	3.98	8.26	0.72
Preempt RT	3.48	4.21	9.32	0.99
Linux std.	3.20	4.69	43.87	4.12

Time Patch	Context switching (us)
Time Patch	Min	Avg.	Max	STDEV
Preempt RT	12.98	15.76	64.36	3.13
Xenomai	11.00	18.38	46.15	3.02
Linux std.	12.67	18.56	267.3	13.87

Time Patch	Task preemption(us)
Time Patch	Min	Avg.	Max	STDEVP
RTAI	21.12	24.44	54.68	4.03
Xenomai	21.17	24.39	42.34	4.80
Preempt RT	4.77	26.71	98.90	12.89
Linux std.	22.22	26.98	278.4	78.56

Time Patch	Task preemption(us)
Time Patch	Min	Avg.	Max	STDEVP
Preempt RT	14.88	29.56	98.65	13.53
Xenomai	12.67	28.41	76.23	10.42
Linux std.	19.99	32.53	476.8	101.89
