Reliability Estimation of Acrylonitrile Butadiene Styrene based on Cumulative Damage

doi:10.23940/ijpe.20.05.p3.702710

Abstract

Abstract:

The study of ABS structures in their different stages of life cycle involves taking into account several complicated phenomena. However, the effect of temperature and geometric discontinuity in the material has been identified as morphological mechanisms responsible for the deterioration of its mechanical properties. Within the framework of this problem, this study is interested in the characterization of ABS performance and the evaluation of the effect of the defect on its mechanical behavior. The influence of discontinuity in the material was assessed by a series of uniaxial tensile tests on virgins and artificially damaged specimens. Subsequently, the results of the experimental tests were used to predict the damage and the instantaneous reliability of the material as well as to find a relationship between these two parameters through the fraction of life, which makes it possible to monitor the degradation of the material and predict the moment of acceleration of the damage. This technique can provide manufacturers with a predictive maintenance strategy.

Key words: ABS, polymer, reliability, damage, life fraction, tensile tests

Fatima Ezzahra Nassih, Achraf Wahid, Fatima Sabah, Hamid Chakir, and Mohamed Elghorba. Reliability Estimation of Acrylonitrile Butadiene Styrene based on Cumulative Damage [J]. Int J Performability Eng, 2020, 16(5): 702-710.

Add to citation manager EndNote|Reference Manager|ProCite|BibTeX|RefWorks

Figures/Tables 21

Figure 1.

Figure 2.

Figure 3.

Table 1

Figure 4.

Figure 5.

Figure 6.

H σ ur σ u = a 1 - β b c

(1)

Figure 7.

σ ur σ u = 1.314 1 - β 1.05 1.47

(2)

D s = 1 - σ ur σ u 1 - σ a σ u

(3)

β = a w

(4)

Figure 8.

D s = 1 - σ ur σ u 1 - σ a σ u = 1 1 - σ a σ u - σ ur σ u 1 - σ a σ u

(5)

β = b (1 - (D - C 1 C 2) 1 c)

(6)

Figure 9.

R (t) = exp (- (t ?) λ)

(7)

R (β) = exp (- (β) λ)

(8)

Figure 10.

R = e - (b (1 - (D - C 1 C 2) 1 d)) λ,

1 e ≤ R < 1

(9)

Figure 11.

References 15.

1.	S. Ramaswamy and A. Lesser, “Microscopic Damage and Macroscopic Yield in Acrylonitrile-Butadiene-Styrene (ABS) Resins Tested under Multi-Axial Stress States,” Polymer, Vol. 43, No. 3, pp. 3743-3752, 2002
2.	D. M. Kulich, S. K. Gaggar, V. Lowry,R. Stepien, “Acrylonitrile-Butadiene-Styrene (ABS) Polymers,”Kirk‐Othmer Encyclopedia of Chemical Technology, 2000
3.	B. Ni, J. Li,V. Berry, “Plastic Zone in Front of a Mode i Crack in Acrylonitrile-Butadiene-Styrene Polymers,” Polymer, Vol. 32, No.15, pp. 2766, 1991
4.	A. Ouardi, N. Mouhib, A. Wahid,M. ELghorba, “Comparative Study of Axial and Circumferential Defects Severity on the Failure of Polypropylene (PPR) Pipes,”Engineering Failure Analysis, Vol. 105, pp. 1201-1211, 2019
5.	Y. L. Yap, W. Toh, R. Koneru, K. Lin, K. M. Yeoh, C. M. Lim, et al., “A Non-Destructive Experimental-Cum-Numerical Methodology for the Characterization of 3D-Printed Materials—Polycarbonate-Acrylonitrile Butadiene Styrene (PC-ABS),”Mechanics of Materials, Vol. 132, pp. 121-133, 2019
6.	F. Sabah, A. Wahid, F. Nassih, M. El Ghorba,H. Chakir, “Prediction of the Lifetime of Acrylonitrile Butadiene Styrene (ABS), by Calculation of Damage by Two Methods: Damage Based on Residual Stresses and Damage by Stages Evolution,”Key Engineering Materials, Vol. 820, pp. 203-211, 2019
7.	F. Sabah, A. Wahid, A. Kartouni, H. Chakir,M. ELghorba, “Failure Analysis of Acrylonitrile Butadiene Styrene (ABS) Materials and Damage Modeling by Fracture,” International Journal of Performability Engineering, Vol. 15, No. 9, pp. 2285, 2019‏
8.	F. Carrasco, O. O. Santana, J. Cailloux, M. Sanchez-Soto,M. LI. Maspoch, “Poly (Lactic Acid) and Acrylonitrile - Butadiene - Styrene Blends: Influence of Adding ABS- g- MAH Compatibilizer on the Kinetics of the Thermal Degradation,”Polymer Testing, Vol. 67, pp. 468-476, 2018
9.	J. C. Riddick, M. A. Haile, R. Von Wahlde, D. P. Cole, O. Bamiduro,T. E. Johnson, “Fractographic Analysis of Tensile Failure of Acrylonitrile-Butadiene-Styrene Fabricated by Fused Deposition Modeling,”Additive Manufacturing, Vol. 11, pp. 49-59, 2016
10.	G. Curtzwiler, K. Vorst, S. Palmer,J. W. Brown, “Characterization of Current Environmentally-Friendly Films,” Journal of Plastic Film and Sheeting, Vol. 24, No.3-4, pp. 213-226, 2008
11.	F. Sabah, A. En-Naji, A. Wahid, M. El Ghorba,H. Chakir, “Study of Damage of the Specimens in Acrylonitrile Butadiene Styrene (ABS), based on a Static Damage Study and Damage by Unified Theory to Predict the Life of the Material,”Key Engineering Materials, Vol. 820, pp. 40-47, 2019
12.	C. Bathias and A. Pineau, (Eds.), “Fatigue of Materials and Structures,” ISTE, 2010
13.	A. Meksem, M. El Ghorba, A. Benali,A. El Barkany, “Optimization by the Reliability of the Damage by Tiredness of a Wire Rope of Lifting,”Applied Mechanics and Materials, Vol. 61, pp. 15-24, 2011
14.	A. Wahid, N. Mouhib, A. Ouardi, A. Kartouni, H. Chakir,M. ELghorba, (2019). “Wire Rope Reliability Assessment based on Damage Mechanics,” International Journal of Performability Engineering, Vol. 15, No. 6, pp. 1744-1750, 2019
15.	A. Wahid, N. Mouhib, A. Kartouni, H. Chakir,M. Elghorba, “Energy Method for Experimental Life Prediction of Central Core Strand Constituting a Steel Wire Rope,” Engineering Failure Analysis, Vol. 97, pp. 61-71, 2019‏
